The side coiling design makes this product ideal for openings in rated walls where headroom clearance is limited and enables the assembly to navigate around tight curves and contoured openings.

The S9000 Series Fire Door Systems are ideal for any application where emergency egress is required and conventional swinging doors would not provide an adequate design solution. Ideal applications are: cross-corridor situations in schools or hospitals. They have been widely designed into casinos, museums and retail spaces in area separations, occupancy separations and elevator lobby separations.

Ratings

3-hour rated UL 10B*

Available with a temperature rise rating of 650°F over 30 minutes when required, single parting only

Smoke & Draft labeled UL 1784

Code Compliance

CCRR-1086

ADA compliant

Egress

Single or multiple fixed complying egress doors available when required

Operation

Auto-Set® automatic resetting

Fail-Safe Design – automatic self-closing mechanism does not require power operation

Size

Widths to 80′ (160′ bi-parting) and heights to 24′; for larger sizes and custom configurations consult the factory

Negotiates radius curves: 3′-0″ with egress doors; 1′-6″ without egress

Finishes

McKEON Sterling Gray

Powder coat of any color as selected

Stainless Steel — No. 4 Polish or No. 8 Mirror

Product Specifications
