S7000 Series doors are side acting therefore ideal for openings in fire walls where headroom is limited. The side activated design enables these fire doors to navigate around tight curves and contoured openings.

The Safescape® S7400, S7500, S7700,and S7900 Fire Door Systems are ideal for any application where fire protection and emergency egress is needed and conventional swinging doors would not provide an adequate and desirable solution. The S7200 and S7600 are ideal for any application where only fire protection is required and egress is not an issue. Ideal applications are: cross-corridor situations in schools or hospitals and area separations. The S7000 Series Fire Door Systems have become increasingly designed into casinos, museums and retail areas.

Ratings

3-hour rated UL 10B*

Available with a temperature rise rating of 650°F over 30 minutes when required, single parting only

Smoke & Draft labeled UL 1784

Code Compliance

CCRR-1086

ADA compliant

Egress

Available with multiple fixed complying swinging egress doors when required

Operation

Auto-Set® automatic resetting

Fail-Safe Design – automatic self-closing mechanism does not require power operation to self-close

Manual operation for assemblies up to 10’x10′

Safescape® S7700 Training Demonstration Video

Size

Widths to 80′ (160′ bi-parting), heights to 24′; for larger sizes and custom configurations consult the factory

Negotiates radius curves: 3′-0″ with egress doors; 1′-6″ without egress doors

Finishes

McKEON Sterling Gray

Powder coat of any color as selected

Stainless Steel — No. 4 Polish or No. 8 Mirror

Product Specifications
