The FireFighter D200E Series is the only protective fire curtain assembly on the market with a 20-minute rating UL10B and UL10C without hose stream, up to 3-hour UL 10D rating, UL 1784 smoke and draft rating and integral conforming swing egress door(s). “The First Responder” is truly a first – going beyond where others leave off!

The D200E incorporates an egress feature that complies with the current model building codes as an opening protective placed in the required path of egress. Swinging doors as outlined in the egress sections of the model codes are the basis of design and acceptance for the FireFighter D200E fire curtain and its many applications where building occupant egress is required.

Ratings

20-minute rated UL 10B & 10C without hose stream

Up to 3-hour rated UL 10D

UL 1784 tested and listed without an artificial bottom seal

Code Compliance

Code Compliance Research Report CCRR-0455



ADA compliant

Egress

Available with up to 8 complying swing egress doors

Operation

Auto-Set® automatic resetting

Fail-Safe Design – automatic self-closing mechanism does not require power operation to self-close

FireFighter® D200E Training Demonstration Video

Size

Widths to 60′ and heights to 24′; for larger sizes and custom configurations consult the factory

Finishes (metal components only)

McKEON Sterling Gray

Powder coat of any color as selected

Stainless Steel — No. 4 Polish or No. 8 Mirror

Product Specifications
